NISMO unveiled its DOHC head for L-type engines for the first time in the world at Nostalgic 2 Days 2024
This was developed over several years to commemorate the 40th anniversary of the NISMO brand, which was established in 1984.
By combining the originally SOHC L-type engine with a DOHC head, the engine type is said to be the ``TLX type.'' A timing chain is used to drive the cam.
■Engine main specifications Specifications
Engine type TLX
Engine type Water-cooled in-line 6-cylinder
valve mechanism DOHC (chain drive)
Bore x Stroke ⌀89.0mm x 79.0mm
Total displacement 2949cc
Compression ratio 12.5:1
Maximum output 221kW (300ps) or more
Maximum torque 294N・m (30kgfm) or more
Maximum rotation speed 7500rpmFuel
supply system Multi-port injection
